Desktop Power Adapter
24V 6A 144W Desktop Power Adapter
LX-2460 High-Power Desktop Adapter
Model: LX-2460
Output: 24V DC / 6A
Rated Power: 144W
Designed for 24V DC equipment such as water purification, dispensing and control systems, with configurable input cord, DC connector, cable length, label and packaging.
- Input
- 100-240V AC, 50/60Hz
- Output
- 24V DC, 6A
- DC Connector
- 5.5 x 2.5 mm
- Dimensions
- 170 x 67 x 38 mm
- Protection
- OVP / OCP / SCP / OTP
- Input Cord
- US / EU / UK / AU options
Page data supports initial project evaluation. Final production specifications, polarity and compliance documents are subject to engineering confirmation.
Technical Data
Core Data for Purchasing and Engineering Review
| Brand | LinkStar |
|---|---|
| Model | LX-2460 |
| Input | 100-240V AC, 50/60Hz |
| Output | 24V DC, 6000mA, 144W |
| DC Plug | 5.5 x 2.5 mm |
| Protection | Over-voltage, over-current, short-circuit and over-temperature protection |
| Packing | White box or color box |
| Carton | 50 pcs, 49 x 22 x 53 cm, approx. 17 kg |
What to Confirm Before Sampling
- Device rated power, peak current and continuous load
- DC connector size, polarity and cable length
- Target market and AC input cord standard
- Compliance, label, packing and estimated quantity
RFQ
Share Your Device Requirements for Engineering Review
Please include load type, connector, target market, AC cord, estimated quantity and compliance requirements.
